| 型号 | A mm | C mm | D mm | G mm | H mm | J mm | L mm | M mm | N mm |
| 1/4 | 116 | 17 | 10 | 18 | 41 | 57 | 40 | 33 | 9 |
| 5/16-3/8 | 123 | 21 | 13 | 21 | 43 | 57 | 44 | 38 | 11 |
| 7/16-1/2 | 142 | 25 | 15 | 24 | 51 | 64 | 51 | 48 | 13 |
| 9/16-5/8 | 172 | 30 | 18 | 28 | 60 | 76 | 64 | 57 | 14 |
| 3/4 | 202 | 35 | 21 | 32 | 70 | 89 | 76 | 67 | 16 |
| 7/8 | 235 | 41 | 24 | 38 | 84 | 102 | 89 | 80 | 20 |
| 1 | 269 | 51 | 29 | 44 | 95 | 114 | 102 | 95 | 22 |
| 11/8 | 303 | 57 | 32 | 51 | 107 | 127 | 117 | 105 | 25 |
| 11/4-1 3/8 | 335 | 64 | 38 | 57 | 122 | 140 | 127 | 121 | 29 |
| 11/2 | 384 | 70 | 41 | 70 | 136 | 152 | 152 | 137 | 30 |
| 15/8 | 412 | 76 | 44 | 76 | 142 | 165 | 165 | 146 | 33 |
| 13/4-1 7/8 | 464 | 89 | 51 | 8o | 169 | 191 | 178 | 165 | 40 |
| 2-21/8 | 545 | 95 | 57 | 95 | 194 | 228 | 228 | 178 | 46 |
| 2 1/4-2 3-8 | 606 | 108 | 64 | 102 | 222 | 254 | 254 | 197 | 54 |
| 2 1/2-25-8 | 654 | 121 | 73 | 114 | 247 | 273 | 273 | 216 | 60 |
| 2 3/4-2 7/8 | 692 | 127 | 79 | 124 | 279 | 279 | 279 | 229 | 73 |
| 3-3 1/8 | 737 | 133 | 86 | 133 | 298 | 305 | 286 | 241 | 76 |
| 3 1/4-3 3/8 | 784 | 140 | 92 | 146 | 317 | 328 | 298 | 254 | 79 |
| 3 1/2-3 5/8 | 845 | 152 | 99 | 165 | 338 | 360 | 318 | 273 | 83 |
| 3 3/4-4 | 921 | 178 | 108 | 184 | 36g | 389 | 343 | 318 | 89 |
